U3SM100USM UHF IS SPLITTER 3 WAY DC ROUTING
smartcom 450IS

U3SM100USM UHF IS SPLITTER 3 WAY DC ROUTING

Becker Mining Systems’ smartcom® 450 termination unit is required at the end of each Leaky Feeder cable branch to absorb RF signals, prevent¬ing reflections and distortion.

  • End of line unit
  • Absorbs RF signals
  • Prevents reflections and distortions
  • N-type connectors
  • 50 ohm impedance

U3SM100USM UHF IS SPLITTER 3 WAY DC ROUTING: Product inquiry

Do you need more information regarding this product or do you want to integrate this product into your solution? Feel free to use the form below or reach out to a local contact person.

Fields are required.

Technical information

Frequency Band

Handheld to Base 445 MHz to 455 MHz (Uplink), Base to Handheld 470 MHz to 480 MHz (Downlink)

Impedance

50 Ω

Connectors

50 Ω Brass Blocks

Insertion Loss

<6dB

Through Current Capacity

3.0A max.

U3SM100USM UHF IS SPLITTER 3 WAY DC ROUTING: Full technical information

Frequency Band Handheld to Base 445 MHz to 455 MHz (Uplink), Base to Handheld 470 MHz to 480 MHz (Downlink)
Impedance 50 Ω
Connectors 50 Ω Brass Blocks
Insertion Loss <6dB
Through Current Capacity 3.0A max.
Operating Temperature -20 to +40° C
Operating Humidity 10% to 85% (Non Condensing)
Protection Class IP68 according to EN60529
Impact Resistance 7 Nm
Flammability UL94 V-O
Enclosure Kestrel ‘KE’ & ‘POK’ glass reinforced polyester type
Dimensions 61 x 75 x 160 mm
Weight 990 g
Technical details may vary between different product versions.
